Ultrasonic Thickness Gauge w/ Data Logging
Panomex Ultrasonic Thickness Gauges are advanced ultrasonic instruments designed for accurate ultrasonic thickness testing and are considered exceptional in their class. Featuring an ergonomic design, rugged construction, and user-friendly operation, these meters are ideal for non-destructive testing (NDT) applications. Simple, precise, and robust, Panomex ultrasonic thickness gauges are widely used for measuring material thickness and corrosion in pressure vessels, chemical equipment, boilers, oil storage tanks, and similar assets across industries such as petroleum, shipbuilding, power generation, and machine manufacturing.
Often referred to as ultrasonic wall thickness gauges, these handheld, microprocessor-controlled instruments are capable of data logging and reliable thickness measurement even under harsh working conditions. To ensure durability in extreme environments, Panomex ultrasonic thickness gauges are built with tough housings and supplied with a hard-shell carrying case. Models are available with coating measurement capability and without coating, allowing users to select the most suitable option for their inspection requirements.
| Display |
LCD Display |
|---|---|
| Operating principle |
Ultrasonic |
| Materials measured |
steel, cast iron, aluminum, red copper, brass, zinc, quartz glass, polyethylene, PVC, gray cast iron, nodular cast iron etc. |
| Sound velocity |
500-9000m/s |
| Lower limit steel pipes |
ф15×2.0mm, ф20×3.0mm determined by the transducer |
| Calibration block |
Included |
| Resolution |
0.1mm |
| Accuracy |
±(0.5%n+0.1) |
| Memory |
10 Readings |
| Unit |
MM / Inch |
| V-path correction |
Automatic |
| Data Output |
RS232C Interface |
| Power supply |
6 Volt Battery |
| Battery indicator |
Low Battery indicator |
| Operating Temperature |
0 – / + 45°C (32°F-104°F), ≤ 90 % RH |
| Accessory |
Hard Shell Carrying Case |
